35
B760 Pro RS/D4
ATX Power Connector
(24-pin ATXPWR1) (see p.6, No. 11)
is motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX
power supply, please plug it along Pin 1 and Pin 13.
ATXPWR1
12
1
24
13
