45
B760 Pro RS/D4
A
A
20
o
Step 3
Gently insert the WiFi/BT PCIe WiFi
module or Intel® CNVi (Integrated
WiFi/BT) into the M.2 slot. Please be
aware that the module only ts in one
orientation.
A
Step 4
Tighten the screw with a screwdriver
to secure the module into place.
Please do not overtighten the screw as
this might damage the module.
