29
B760 Pro RS/D4
USB 2.0 Header
(9-pin USB_3_4) (see p.6, No. 24)
ere is one header on this motherboard. is USB 2.0 header can support two
ports.
DUMMY
GND
GND
P+
P-
USB_PWR
P+
P-
USB_PWR
1
USB_3_4
