27
B760 Pro RS/D4
Chassis Intrusion and Speaker Header
(7-pin SPK_CI1) (see p.6, No. 27)
Please connect the chassis intrusion and the chassis speaker to this header.
SPK_CI1
1
+5V
DUMMY
SIGNAL
GND
DUMMY
SPEAKER
DUMMY
