English
9
STANDARD ACCESSORIES
In addition to the main unit (1), the package contains
the accessories listed in the table below.
Standard accessories are subject to change without
notice.
OPTIONAL ACCESSORIES (sold separately)
1. Battery
(BSL1415)
(For DS14DSFL)
2. Battery (BSL1815)
(For DS18DSFL)
Optional accessories are subject to change without
notice.
APPLICATIONS
䡬 Driving and removing of machine screws, wood
screws, tapping screws, etc.
䡬 Drilling of various metals.
䡬 Drilling of various woods.
BATTERY REMOVAL/INSTALLATION
1. Battery removal
Hold the handle tightly and push the battery latch
to remove the battery (see Figs. 1 and 2).
CAUTION
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (see
Fig. 2).
CHARGING
Before using the driver drill, charge the battery as follows.
1. Connect the charger’s power cord to the receptacle.
When connecting the plug of the charger to a
receptacle, the pilot lamp will blink in red.
(At 1-second intervals).
2. Insert the battery into the charger.
Firmly insert the battery into the charger till it
contacts the bottom of the charger and checking
the polarities as shown in Fig. 3, 4.
CAUTION:
䡬 If the batteries are inserted in the reverse direction,
not only recharging will become impossible, but it
may also cause problems in the charger such as
a deformed recharging terminal.
SPECIFICATIONS
POWER TOOL
Model DS14DSFL DS18DSFL
No-load speed (Low/High) 0 – 450 / 0 – 1250 min
–1
0–450 / 0 – 1250 min
–1
Wood
Drilling
(Thickness 18mm)
30 mm 38 mm
Metal
Steel: 12 mm Steel: 13 mm
(Thickness 1.6mm)
Machine screw 6 mm 6 mm
Driving
Wood screw
6.0 mm (diameter) × 75 mm (length) 6.8 mm (diameter) × 50 mm (length)
(Requires a pilot hole) (Requires a pilot hole)
Rechargeable battery
BSL1415 Li-ion 14.4 V (1.5 Ah 4 cells) BSL1815 Li-ion 18 V (1.5 Ah 5 cells)
Weight 1.5 kg 1.7 kg
Capacity
CHARGER
Model UC18YGSL
Charging voltage 14.4 – 18V
Weight 0.4 kg
CAUTION
1. If liquid leaking from the battery gets into your
eyes, do not rub your eyes and wash them well
with fresh clean water such as tap water and
contact a doctor immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well
with clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return
it to your supplier or vendor.
WARNING
If a conductive foreign matter enters in the terminal
of lithium ion battery, the battery may be shorted,
causing fire. . When storing the lithium ion battery,
obey surely the rules of following contents.
䡬
Do not place conductive debris, nail and wires
such as iron wire and copper wire in the storage
case.
䡬
To prevent shorting from occurring, load the
battery in the tool or insert securely the battery
cover for storing until the ventilator is not seen
(See Fig. 1).
1 Plus driver bit (No. 2 × 65L) ........... 1
2 Charger .................................................. 1
3 Plastic case ............................................ 1
4 Battery .................................................... 2
(DS14DSFL : BSL1415)
(DS18DSFL : BSL1815)
5 Battery cover ......................................... 1
DS14DSFL
DS18DSFL
01Eng_DS14DSFL_EE 6/8/10, 6:56 PM9
