PERFORMANCE SPECIFICATIONS
Inputs
Analogue line inputs 16
Connector 25-way female Dsub x 2, wired to AES 59
0 dBFS reference levels +18 or +24 dBu (switchable)
Frequency response 20 Hz – 20 kHz ±0.05 dB
THD+N < 0.001% unweighted; -1 dBFS input, 20 Hz – 22 kHz
Dynamic range 119 dB ‘A’-weighted (-60 dBFS method)
Converter dynamic range 120 dB
Signal-to-noise ratio 119 dB ‘A’-weighted; 20 Hz – 20 kHz
Outputs
Analogue line outputs 16
Connector 25-way female Dsub x 2, wired to AES 59
0 dBFS reference levels +18 or +24 dBu (switchable)
Frequency response 20 Hz – 20 kHz ±0.15 dB
THD+N < 0.001% unweighted; -1 dBFS input, 20 Hz – 22 kHz
Dynamic Range 119 dB ‘A’-weighted (-60 dBFS method)
Converter dynamic range 120 dB
Signal-to-noise ratio 119 dB ‘A’-weighted; 20 Hz – 20 kHz
Crosstalk
Input or Output to Input < -90 dB (all other channels at 0 dBFS)
Input or Output to Output < -100 dB (all other channels at 0 dBFS)
Digital Performance
Supported sample rates 44.1 / 48 / 88.2 / 96 / 192 kHz
Clock sources Internal or from network master device
Power
PSU Internal, Universal type, consumption 68 VA
Front Panel Indicators
Power Green
Network connected Green
Sync lock Green
Sample rate Yellow x 5
Input/Output range Yellow x 2
Input/Output signal level Bi-colour x 32 (Green = -42 dBFS; Orange = -6 dBFS; Red = overload)
