Focusrite RedNet PCIe R Card [30/66] Rednet 4

Power

PSU Internal, Universal type, consumption 45 VA

Front Panel Indicators

Power Green

Network connected Green

Sync lock Green

Sample rate Yellow x 5

Channel 1/2 source Yellow x 3 (mic/line/inst)

Signal level Green x 8 (-42 dBFS); Yellow x 8 (-6 dBFS); Red x 8 (overload)

Channel select buttons 8

Channel function controls Input source, HPF, phantom power, Gain encoder

Channel display Colour OLED; channel number, input source, gain

REDNET 4
