PERFORMANCE AND SPECIFICATIONS
Audio Inputs
AES/EBU 16 channels, with switchable SRC by input pair
AES/EBU Connectors
1–16: 2x 25-way female D-Sub, each wired to AES59 (combined I/O)/Tascam Digital
Channels 1–2 (switchable): XLR3F
S/PDIF Input Channels 3–4 (switchable)
S/PDIF connector RCA Phono socket
Input format Channel status ignored. Assumed to be 24 bit, 2-channel audio
Audio Outputs
AES/EBU 16 channels, synchronous with unit sample rate
AES/EBU Connectors
Channels 1–16: 2x 25-way female D-Sub, each wired to AES59 (combined I/O) (See
“Inputs”)
Channels 1–2: XLR3M
S/PDIF Output
2 channels, synchronous with unit sample rate Output can duplicate any adjacent odd/
even pair of channels 1–16
S/PDIF connector RCA Phono socket
Output format AES3
Input Sample Rate Converters
Input sample rate range 32 to 216 kHz
Gain error -0.3 dB
Dynamic Range > 138 dB (-60 dBFS method)
THD+N < -130 dB (0.00003%); 0 dBFS input
Input format Channel status ignored. Assumed to be 24 bit, 2-channel audio
Latency 11 to 45 samples (network and input sample rate dependent)
Digital Performance
Supported sample rates 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz (-4% / -0.1% / +0.1% / +4.167%) at 24 bit
Clock Sources Internal or from network master device
External word clock range Nominal sample rate ±7.5%
