REDNET D16 OPERATION
FIRST USE AND FIRMWARE UPDATES
Your RedNet D16 will require a firmware update when it is first installed and switched on. Firmware
updates are initiated and handled automatically by the RedNet Control application. It is important
that the firmware update procedure is not interrupted, either by switching off the RedNet D16 or the
computer on which RedNet Control is running or disconnecting either from the network.
From time to time Focusrite will release RedNet firmware updates within new versions of RedNet
Control. We recommend keeping all RedNet units up to date with the latest firmware version supplied
with each new version of RedNet Control.
PULL UP AND PULL DOWN OPERATION
RedNet devices are able to run with pull up or pull down sample rates in one of two ways:
• Locking to an external clock at the desired clock frequency
• Operating at a specified pull up or pull down percentage as selected in the Dante Controller
application*
* Note: Not all RedNet devices currently support this mode of operation.
SAMPLE RATE CONVERTERS
SRC will need to be switched in for any sources that are not using the current system clock as a
reference signal.
SRC can be switched in or out separately for each input channel pair.
* Note: SRC increases latency slightly.
