![Focusrite RedNet PCIe R Card [56/66] Rednet d16](/views2/1989828/page56/bg38.png)
56
Indicators
Power Indicator Green LED
Primary network
Green LED. Indicates that a network connection is present on primary port when in
redundant mode. When in Switched mode, a valid network connection at either Primary or
Secondary network port will cause this LED to illuminate.
Secondary network
Green LED. Indicates that a network connection is present on secondary port when in
redundant mode. Not used in switched mode.
Locked
Green LED. When unit is network slave, shows valid network lock, when network master
shows unit is locked to indicated clock source. Flashing means invalid external clock
present and unit has reverted to internal clock.
Unit sample rate Orange LED for each: 44.1 kHz, 48 kHz, x2, x4
Pull/up down Indicates unit is set to operate on a Dante pull up/down domain
Signal indicators 16 Green LEDs, 8 input/8 output indicators. Illuminate at -126 dBFS
Clock source indicators Orange LED for each: Internal, Word Clock, DARS, Input 1–2, Input 9–10
Network Modes
Redundant Allows unit to connect to two independent networks
Switched Connects both ports to integrated network switch allowing daisy-chaining of device
Power
PSU
Internal, 100-240V, consumption 30 VA
REDNET D16
