48
PERFORMANCE SPECIFICATIONS
Word Clock
Connectors BNC 75Ω
Output 5V 75Ω DC-coupled
Input locks down to 0.2V AC-coupled (75Ω software switchable termination)
MADI Coaxial
Electrical standard as per AES10:2008
Recommended Cable 75Ω characteristic impedance
Connector BNC 75Ω
MADI Optical
Optical Standard as per AES10:2008 (ISO/IEC 9314-3, FDDI, ANSI X3.166)
Recommended Cable Multi-mode, Graded-index, 62.5µm core, 125µm cladding
Connector Duplex-SC
SRC
SRC lock range 41kHz to 216kHz (MADI)
Sample Rate Ratio Limit 6:1
THD -130dB typical
Latency 43 to 196 samples (Network and MADI sample rate dependent)
Channel Count RedNet Clock
MADI Clock Single Double Quad
Single 64 32 16
Single Varispeed 56 32 16
Double 32 32 16
Double Varispeed 28 28 16
Quad 16 16 16
Quad Varispeed 14 14 14
Power
PSU Internal, Universal type, consumption 30VA
REDNET 6
