REDNET D16
UNIT CONNECTIONS AND FEATURES
RedNet 6 - Front Panel
1. AC Power Switch
2. Power Indicator
3. RedNet Network Status Indicators:
• PRIMARY – illuminates when the device is connected to an active Ethernet network.
• SECONDARY – illuminates when the device is connected to an active Ethernet network.
Not used when operating in Switched mode.
• LOCKED – illuminates when a valid sync signal is received from the network or
the RedNet D16 unit is network master. When an incoming clock signal is invalid,
the Locked indicator will flash to indicate that the unit has reverted to using its
internal clock.
4. RedNet Sample Rate Indicators
Five orange indicators: 44.1 kHz, 48 kHz, x2 (multiple of 44.1 or 48), x4 (multiple of 44.1 or 48)
and sample rate PULL UP/DOWN. These Indicators illuminate individually or in combination
to indicate the sample rate being used. For example, for a 96kHz pull up/down setting, the
48kHz, x2 and Pull Up/Down indicators will illuminate.
5. Signal Presence LEDs
Indicate that an input or an output signal is present for each odd/even channel pair. Illuminate
at -126dBFS.
6. Clock source
Five orange indicators: Word Clock, Input 1-2, Input 9-10, DARS and Internal. Whichever is
lit identifies the clock reference being used. (When the unit is not a network master, no LEDs
