2.3 Installation Diagram
1). Handling
a. Use a padded trolley to protect the refrigerator while moving, as shown in the figure.
b. Remove all packing materials and bottom pads before moving the refrigerator indoors for
placement.
c. Leave it for 2 hours before powering on.
2). Installation position
The refrigerator is installed in cabinet as follows:
3). Changing the left and right swing of door
The door opening direction of
refrigerator is right
-handed by default. If you want to change it to
8
Cross screwdriver
List of tools to be provided by the user
5/16″
socket and ratchet
Masking tape
Putty knife
thin-blade screwdriver
