Midea MDRE354FGF01M [9/57] Dimensions of refrigerator and cabinet
![Midea MDRE354FGF01M [9/57] Dimensions of refrigerator and cabinet](/views2/2017606/page9/bg9.png)
7
2.2 Dimensions of refrigerator and cabinet
1). Size of refrigerator
2). Size of cabinet (recommended)
555~562mm
>
50mm
560mm
1071+A~1079+Amm697+Amm
1776+2A~1784+2Amm
1785
63
1007622.5
1770
540
550
4mm
A
1776~1784mm
>
A:thickness of
cabinet board
200cm
2
1800~2000mm
>
4mm
