ПЕРЕНАВЕШИВАНИЕ ДВЕРИ
Крестовая отвертка
Трещотка 8 мм
Шпатель и отвертка
с тонким лезвием
Малярный скотч
Выключите прибор перед переустановкой двери. Уберите все продукты с дверных полок.
При помощи плоской отвертки выньте декоративную накладку верхнего шарнира, 2
верхних заглушки, среднюю заглушку, а также декоративную накладку нижнего шарнира и
2 нижних заглушки. Зафиксируйте дверь скотчем.
Верхняя накладка
Заглушки
Средняя заглушка
Верхний шарнир
Нижний шарнир
RUS-19
