![Zalman Z9 Plus [12/69] 6 front cover installation](/img/pdf.png)
Zalman Z9 Plus [12/69] 6 front cover installation
![Zalman Z9 [12/69] 6 front cover installation](/views2/1111185/page12/bgc.png)
10
Z9 Series
B. 3.5” HDD Installation
3.5” HDD
3.5” HDD
C. 2.5” SSD Installation
SSD
SSD
(6) Front Cover Installation
A Bolt
B Bolt
When removing the front cover, the power switch and extension
cable are separated to prevent disconnection. Be sure to
connect them before installing the front cover.
Caution
