Zalman Z9 Plus [57/69] Z9 series
![Zalman Z9 [57/69] Z9 series](/views2/1111185/page57/bg39.png)
4
Z9 Series
(5) Parts
Brida cable x 5
extensión del cable de
extensión cable x 1 CPU
5 tuercasMain Unit
Tornillo A (# 6-32 * 6 mm) x 11
[PSU, PCI]
Tornillo B (M3 * 5 mm) x 17
[placa base HDD, SSD]
Tornillo D (# 6-32 * 4 mm) x 20
[3.5'' HDD bay]
Tornillo C (M3 * 6 mm) x 12
[5.25 bahía'' ODD]
anti-vibraciones de goma HDD x 20
[3.5'' HDD bahía]
Manual de usuario
Manual
Tornillo E (# 6-32 * 6 mm) x 5
[3.5'' HDD]
