Zalman Z9 Plus [21/69] 제품개요
![Zalman Z9 Plus [21/69] 제품개요](/views2/1111185/page21/bg15.png)
2
Z9 Series
2
제품개요
(1) 제품 사양
※ USB 3.0포트는 제품에 따라 옵션사항으로 지원합니다.
구분
Z9 Series
타입 ATX Mid Tower
크기 (W x H x D) 207 × 464 × 504㎜ (8.1 × 18.2 × 19.8”)
재질 Plastic, Steel
색상 블랙
지원 마더보드 규격 Standard ATX / m-ATX
지원 파워서플라이 규격
Standard ATX / ATX12V
PCI / AGP 카드 규격 Full Size 290㎜ (11.4")
드라이브
베이
5.25" 외장 3개
3.5" 외장 1개, 내장 5개
5.25"/3.5"/2.5" 1개 (3in1)
Hot-swap -
확장슬롯 7개
쿨링구성요소
전면
120㎜ 또는 140㎜ 팬 × 1 (기본장착)
상단
Z9 PLUS/
Z9D Series
120㎜ 또는 140㎜ 팬 × 2 (1 기본장착,1 옵션)
Z9
120㎜ 또는 140㎜ 팬 × 2 (옵션)
하단
120㎜ 또는 140㎜ 팬 × 1 (옵션)
후면
120㎜/140mm 팬 × 1 (기본장착)
측면
Z9 PLUS/
Z9D Series
120㎜ 팬 × 2 (1 Blue LED 팬 기본장착,1 옵션)
Z9
120㎜ 팬 × 2 (옵션)
전면 I/O포트
Z9 Plus /
Z9D series
마이크 × 1/ 헤드폰 × 1/ 팬 컨트롤러 / 온도 디스플레이
USB 2.0 x 4 ( or USB 2.0 x 2 / USB 3.0 x 2)
Z9
마이크 x 1 / 헤드폰 x 1 / USB 2.0 x 4
