3
ENG
Z9 Series
(2) Product Information
Front Top Side (left)
(3) Front Panel I/O Ports
Mic
Headphones
HDD LED
Reset Button
USB 2.0
USB 2.0 USB 2.0
RESET
HDD
MIC HEADPHONE
USB 2.0
(or USB 3.0)
Power Button
Temperature Display
Fan Controller
※ Temperature and Fan Controller display are only available on the Z9 Plus, Z9D Series.
