3
ENG
Z9 Series
(2) 제품 외관
전면 상단 측면(왼쪽)
(3) 전면 I/O 포트
Mic
Headphones
HDD LED
Reset Button
USB 2.0
USB 2.0 USB 2.0
RESET
HDD
MIC HEADPHONE
USB 2.0
(or USB 3.0)
Power Button
온도 표시 창
Fan Controller
※ 온도 표시창 및 팬 컨트롤 기능은 Z9 Plus, Z9D Series에만 제공됩니다.
