Zalman Z9 Plus [23/69] 4 구성품
![Zalman Z9 Plus [23/69] 4 구성품](/views2/1111185/page23/bg17.png)
4
Z9 Series
(4) 구성품
케이블 타이 × 5 CPU 12V 연장 케이블 × 1
Stand-Off × 5
본체
A 나사(#6-32*6mm) × 11
[PSU 장착용, PCI 슬롯 고정용]
E 나사(#6-32*6mm) × 5
[3.5” HDD 고정용]
B 나사( M3*5mm) × 17
[M/B, FDD, SSD 장착용]
D 나사(#6-32*4mm) × 20
[3.5” 베이 HDD 장착용]
C 나사(M3*6mm) × 12
[5.25”베이 ODD 장착용]
HDD 방진 고무 × 20
[3.5” 베이 HDD 장착용]
설명서 1부
