Zalman Z9 Plus [30/69] 한 글
![Zalman Z9 [30/69] 한 글](/views2/1111185/page30/bg1e.png)
11
ENG
Z9 Series
(7) 3.5” HDD 장착
HDD
HDD
HDD
HDD
HDD
참 고
선정리 방법에 따라 HDD의 장착 방향을 다르게 할 수 있습니다.
장착 방법에 따라 방진고무와 나사의 장착 위치를 다르게 해야합니다.
A타입 B타입
1) HDD 방진 고무, 나사 결합
2) HDD 장착
HDD 방진 고무
3.5”베이에 삽입 후 ‘딸깍’ 소리가 날 때까지 밀어 넣어 장착합니다.
D 나사
