Zalman Z9 Plus [15/69] 9 cable connection
![Zalman z9 plus, w/o psu, black [15/69] 9 cable connection](/views2/1111185/page15/bgf.png)
13
ENG
Z9 Series
1) Power Button Cable
(9) Cable Connection
Power LED
Power
Motherboard
Power Button
or
(8) SSD Installation
SSDs can be installed on the right side of case as shown in the diagram below.
B Bolt
