6
Z9 Series
(2) 파워 서플라이 설치
A 나사
▶ A Type(PSU 독립 쿨링형)
파워서플라이의 팬이 케이스 하단을 향하면 파
워서플라이의 냉각효과가 향상됩니다.
▶ B Type(케이스 내부 공기 흡입형)
파워서플라이의 팬이 케이스 내부를 향하면 시
스템의 냉각효과가 향상됩니다.
※ 시스템 주변에 먼지가 많을 경우 B Type으로 구성하십시오.
참 고
