11
ENG
Z9 Series
(7) 3.5” HDD Installation
HDD
HDD
HDD
HDD
HDD
Tip
The HDD can be installed in 2 dierent directions, according to your desired
Cable Management style.
A Type B Type
1) Installation of HDD Anti-static rubber and Bolt
2) HDD Installation
HDD Anti-static
rubber
Push into the 3.5” Bay until a “click” sound is heard.
D Bolt
