Zalman Z9 Plus [55/69] Presentación
![Zalman Z9 DIII [55/69] Presentación](/views2/1111185/page55/bg37.png)
2
Z9 Series
2
Presentación
(1) Especificaciones
Modelo
Z9 Series
Tipo ATX Mid Tower
Dimensiones (a x l x a) 207 × 464 × 504㎜ (8.1 × 18.2 × 19.8”)
Materia Plastic, Steel
Color Negro
Placa base Standard ATX / m-ATX
Fuente de alimentación
Standard ATX / ATX12V
Compatibilida tarjeta gráfica Hsta 290 mm (11.4")
Bahías
5.25" Bahías externas x 3
3.5" Bahías externas x 1, Bahías internas x 5
5.25"/3.5"/2.5" Bahías internas 5.25’’ / 3.5’’ / 2.5’’ x 1 (3 en 1)
Hot-swap -
Ranuras de expanción 7
Composants
de
refroidissement
Frontal Ventilador 1 x 120 / 140mm (incluido)
Superior
Z9 PLUS/
Z9D Series
Ventilador 2 x 120 / 140mm
(incluido / opcionales)
Z9 Ventilador 2 x 120 / 140mm (opcionales)
Inferior Ventilador 1 x 120 ó 140mm (opcionales)
Lateral Ventilador 1 x 120 / 140mm (opcionales)
Side
Z9 PLUS/
Z9D Series
Ventilador 2 x 120mm
(1 Blue LED Fan incluido / 1 opcionales)
Z9 Ventilador 2 x 120mm (opcionales)
Puerrto I/O en
el
panel frontal
Z9 Plus /
Z9D series
1 x audifonos, 1 x microfono, Pantalla de
temperatura, Controlador de ventilador
USB 2.0x4 (or USB 2.0 x 2 / USB 3.0 x 2)
Z9 1 x audifonos, 1 x microfono, 4 x USB 2.0
※ El puerto USB 3.0 es apoyado como opción, dependiendo del producto.
