13
ENG
Z9 Series
1) 전원버튼 케이블 연결
(9) 케이블 연결
Power LED
Power
마더보드
전원 버튼
or
(8) SSD 장착
다음 그림과 같이 케이스 오른쪽 측면에 SDD를 장착하여 사용할 수 있습니다.
B 나사
