I/O SETUP
22
not. If your MIDI device or foot controller is capable of
using this function, you should select Fine or Coarse.
(Please refer to your MIDI device/Foot Controller owners
manual to make sure which type the current product is
using). If set to “disabled”, the G-Force will act as a
standard MIDI product.
Bank size
The bank size is used to adapt the G-Force to different
board manufacturers when recalling preset above #128. In
most cases this parameter should be set at 128, but in
some cases e.g. when using the Roland FC-200, it should
be set at 100.
The bank selection number contained in the program
change is multiplied with this value and the program
change number is added. Please refer to the manual of the
board manufacturer for proper setting.
Sysex device ID
The Sysex ID of the G-Force.
Program change offset
With this parameter you are able to add or subtract to or
from the incoming Prg. change; e.g. the incoming Prg.
change is preset 123, and the offset is set to +1, the Prg.
change will now be 124.
The G-Force presets start at #1.
Mapping mode
Adjusts which bank the MIDI mapping should use:
ROM,USER, CARD or Custom. This means that you can
guide an incoming Prg. change to use the USER bank, or
you can design your own MIDI map.
New Mapping Mode
An “External” mapping mode has been added.
When External mapping mode is selected all presets in all
banks can be accessed from an external MIDI device, via
controller 0 (Coarse), plus a sent program change
according to the following table. Bank Size must be set to
100 and the Fine/Coarse parameter must be set according
to the sending device. These parameters are both set-up in
the “I/O Setup - MIDI” menu.
Please note that “Coarse” must
be selected when a
G•Minor is used as sending device.
Controller
Value
0 0 Rom bank preset 1 to 100
0 1 Rom bank preset 101 to 200
0 2 Rom bank preset 201 to 225
0 3 User bank preset 1 to 100
0 4 Card Bank 1 preset 1 to 100
0 5 Card Bank 2 preset 1 to 100
-- -- --
0 9 Card Bank 6 preset 1 to 99
The number of card banks available depends on the size
of the PCMCIA card.
Custom Map
In the Custom Map you can decide what every incoming
Prg. change should map to, using the “Map Program
Change No.” and the “Into Preset” parameters.
Map Program change no.
Use this parameter to select the Prg. change you want to
remap.
Into Preset
Use this parameter to set the new destination of the
incoming program change.
MIDI Program Change Re-Transmit
The G-Force is capable of controlling the re-transmission
of an incoming MIDI prg. change. This enables you to not
only remap an incoming program change,but also to
determine whether the current program change should be
re-transmitted to other devices receiving MIDI information
from the G-Force MIDI Output or not.
A prg. change is re-transmitted on the G-Force MIDI
Out connector, while the MIDI Thru connector
transmits a copy of the signals received on MIDI In
connector
Reset Custom Map
Place the cursor on this parameter and press Enter to
Reset the Custom map.
