Tc Electronic G-FORCE [51/63] The blocks

THE BLOCKS

The Reverb Block

The Reverb in the G-Force is based on the heritage of

the M5000 and M2000, and are tuned for guitar use.

REVERB

The Reverb section of the G-Force can create a variety

of Reverb effects including the feature of emulating the

initial reflections of a room which creates some mind

blowing spatial effects until now only available in the TC

M5000.

When using the G-Force reverb, you should see the

reverb as two parts:

1. Initial room reflections

2. The Decay

The initial room reflections are, depending on the size of

the room, the first 50-200ms of the Reverb and it is these

reflections that contains the information of the size and

shape of a room and create the width and most of the

depth experienced in a real hall or room.

The Decay is the later part of a natural reverb which is

experienced as prolonging the sound and creating some

depth behind the source or direct signal, but integrating it

in the spatial characteristics of the hall or room, like you

experience in natural ambience or reverb.

By emulating the initial room reflections the G-Force can

create some very deep and wide stereo images placing

the source or direct signal in the hall/room without using

long decay times which often makes the sound image

very “crowded” and disturbs your playing.

To check out what the initial reflections can do, reduce or

turn down the Decay level in the Decay parameters

section and turn up Room level in the Room parameters

section. Then try to change the Room size and the Room

shape in the Master section and choose the combination

that you like.

Then try to change the Color in the Room parameters

section to find the tonal balance that suits you.

You will hear a short spatial reverb which sounds a little

like a “gated “ reverb. Then at last add the decay by

turning up the Decay level in the Decay parameters

section and select the decay time that you prefer.

You will also hear that you are able to create a very

spatially wide and deep stereo reverb, with a relatively

short and low level decay.

When listening to the Reverb’s initial reflections alone at

a high level and when selecting Room size XL, Grand or

Huge, you might get a “slapback” effect, but by adding

the right length and amount of decay and by balancing

the Room level you will find that it will be transformed

into width and depth.

Square A typical square room with its defined

reflection patterns.

Round A diffuse room with lively reflections.

Curved A soft, yet still defined set of the reflections.

Room size

Sets the size of the room that the initial room reflections

emulate.

It automatically changes the length of the Predelay (the

time until the first reflection appears) and the Decay start

(the time where the Decay tail of the Reverb starts).

The Predelay and the Decay start can be individually

adjusted to another length in the Room and Decay

section of the algorithm.

Box - Tiny - Small - Medium - Large - XL - Grand - Huge

The sizes: Box, Tiny, Grand & Huge are patterns

emulating extreme room sizes.

Reverb level

Adjusts the combined Room level and the Decay level,

and should be seen as a master level.

The Room level and the Decay can individually adjusted

to another relation in the Room and Decay section of the

algorithm. Range +/-50.
