THE BLOCKS
40
Level 1-2
Sets the level of the two pitch voices.
Mix
Mix between direct sound and effect.
In Level
Controls the input level of the block.
Out Level
Controls the output level of the Intelligent Pitcher block.
Mute mode
See Mute mode in the introduction of this chapter.
Custom Scale
The Custom scale enables you to make your own
scale, by specifying the number of notes, the root key
and the specific notes contained in the current scale.
Notes used
Use this parameter to specify the number of notes
within your Custom scale. A Custom scale must contain
a minimum of 4 and maximum of 8 notes.
Tonic
Sets the root key of your Custom Scale.
Note 2 - 8
Use these parameters to specify the notes you want in
your Custom scale. You can only specify the number
notes set by the “Notes Used” parameter. The Custom
scale must be described within an octave.
Fixed 1 & 2 Voice Pitch
Voice 1-2
Sets the amount of pitch on each of the two voices.
Maximum pitch is +/- 12 semitones.
Delay 1-2
Sets the Delay of the each of the two voices. Maximum
delay time per voice is 400 ms.
Level 1-2
Sets the level of the two pitch voices.
Pan Position 1-2
Controls the panning of each of the two pitch voices.
Feedback 1-2
Sets the amount of Feedback on the two voices. This
can create really weird effects since the signal will be
pitched over and over meaning that it will rise/fall more
and more over a period of time.
Mix
Mix between direct sound and effect.
In Level
Controls the input level of the block.
Out Level
Controls the output level of the Pitch block.
Mute mode
See Mute mode in the introduction of this chapter
2 Voice 2 Octave
Voice 1 & Voice 2
Sets the amount of pitch on each of the two voices.
Maximum pitch is +/- 24 semitones.
Delay - Voice1 & Voice 2
Sets the Delay of the each of the two voices. Maximum
delay time per voice is 400 ms.
Pan Position 1-2
Controls the panning of each of the two pitch voices.
Feedback 1-2
Sets the amount of Feedback on the two voices. This
can create really weird effects since the signal will be
pitched over and over meaning that it will rise/fall more
and more over a period of time.
Mix
Mix between direct sound and effect.
In Level
Controls the input level of the block.
