38
Curve (only in Advanced)
Sets the curve of the LFO. Choose between: Square,
Sine, or Triangle.
The most common LFO curve in Tremolo is Triangle.
Try the Square waveform with 100% Depth, to
get holes in your guitar sound (called
Transforming).
Pulsewidth (only in Advanced)
Controls the division of the upper and lower part of the
current waveform, e.g. if Pulsewidth is set to 75%, the
upper half of the waveform will be on for 75% of the
time.
LFO Phase (only in Advanced)
An LFO phase change causes a small delay in one of
the waveform starting points. This means that left and
right outputs start the current waveform at two different
points.
Example: If LFO phase is set 180º, left and right will be
exactly opposite.
Mix
Mix between direct sound and effect.
In Level
Controls the input level of the block.
Out Level
Controls the output level of the block.
Mute mode
See Mute mode in the introduction of this chapter.
Pulsewidth
Square
Triangle
Sine
Panner
Speed
Controls the speed of the Panner. The simple Panner
always pans fully left and right.
Tempo
The Tempo parameter sets the relationship to the
global Tempo e.g. if you set it to 1/4T you will get
quarter note triplets of the tapped tempo. 1/4 equals
the BPM (tapped Tempo).
If you select “Ignored” the current parameter will use
the Preset value and will not be affected by the Global
Tempo.
Curve (only in Advanced)
Sets the curve of the LFO. Choose between: Square,
Sine, or Triangle.
The most commonly used curve in Panning is Sine.
Pulsewidth (only in Surround Panner)
Controls the division of the left and right part of the
current waveform, i.e. if Pulsewidth is set to 75%, left
channel will be on for 75% of the time. (see pulsewidth
figure in Tremolo).
LFO Phase (only in Surround Panner)
An LFO phase change causes a small delay in one of
the waveform starting points. This means that left and
right outputs start the current waveform at two different
points.
Example:
If LFO phase is set 180º, left and right will be
exactly opposite.
LFO PHASE
Pan Center
Using this parameter, you can move the center of the
Panner.
90 phase
change
THE BLOCKS
