Tc Electronic G-FORCE [53/63] The blocks
![Tc Electronic G-FORCE [53/63] The blocks](/views2/1011798/page53/bg35.png)
51
THE BLOCKS
Simple Reverb
The Simple Reverb is based on the same algorithm as
the Advanced, but the number of parameters are
reduced to 5. This makes it possible for you to set up the
Reverb easily and quickly
Type
Sets the type of the Reverb, meaning the size and
relationship between Predelay, Early reflections and
Decay automatically. (See Advanced Reverb for further
explanation).
Types: Room, Club, Hall, Church, Cathedral, Grand Hall,
Fast Decay, Slow Decay, Plate, Spring.
Decay time
Sets the length of the reverb decay from
0.01 - 20.0 seconds
Predelay
Allows adjustment of the predelay (the time until the first
reflection appears) which is automatically set when
choosing Type. Range +/-50.
Reverb level
Adjusts the combined Room level and the Decay level,
and should be seen as a master level.
The Room level and the Decay can be individually
adjusted to another relation in the Room and Decay
section of the algorithm. Range +/-50
Color
Sets the tonal color of the initial reflections.
When set to Auto it is linked to High color
Wool - Warm - Real - Clear - Bright - Crisp - Glass -
Extreme.
Mix
This parameter sets the mix relation between the dry
(direct) and the wet signal. If you are using G-Force as
an insert effect this means that your direct signal goes
through the G-Force.
In Level
Controls the input level of the block.
Out Level
Controls the output level of the Reverb block.
Mute mode
See Mute mode in the introduction of this chapter.
Output
The Output section contains a master output level control
and a set of Speaker Filters. All parameters in the Out
Section are global only, which means that they are not
included when you store a preset.
Level
In the Output block, you will find an overall outlevel in
addition to the potentiometer on the front panel. This
Outlevel can be controlled via MIDI or pedal, set up in
the I/O Setup, Control display via the Main Volume
parameter.
The Outlevel is not included in the preset.
Speaker Filters
The Speaker Filters are meant to roll off some high and
low frequencies like a guitar cabinet would do. This will
make it possible to rehearse with the G-Force on your
home stereo using a preamp or pedal and a pair of
headphones.
Filters
Sets the Speaker Filter On/Off.
Locut
The Locut filter cutoff frequency can be either 40 or
80Hz.
Hicut
The Hicut cutoff frequency can be 2,5kHz, 3kHz, 3,5kHz,
4kHz, 4,5kHz or 5kHz.
