Tc Electronic G-FORCE [29/63] Modifier

ADSR 1&2

ADSR’s are used to play short sequences triggered by the

audio input. You set up a number of terms to describe the

current sequence, and a trigger level also known as

Threshold.

Attack

The Attack or rise time of the curve i.e. how long it takes to

go from minimum to maximum level.

Decay

Sets how long it takes the curve to fall back from maximum

to Sustain level.

Sustain

The amount of time that the ADSR will hold the Sustain

level.

Sustain level

The value that will be sent out during the Sustain period.

Release

The amount of time that it takes the ADSR to fall from

Sustain level to zero. Release time will take over when the

Sustain time has expired (depending on the trig mode

setting).

Mode

With the mode parameter parameter you can choose the

way the ADSR should respond to trigs. In general the

ADSR can only retrig if the signal falls below threshold and

comes back up.

Once - Will run the ADSR to the end once, and

afterthat be ready for a new trig. In

“Once” mode the signal have to drop

below threshold after the ADSR finished

to be able to retrig.

Once-Retrig - Will run the ADSR to end once, but are

capable of retriggering during the ADSR

sequence.

Loop - Will keep running the ADSR sequence

for as long as the signal stays above

threshold.

Loop-Retrig - Will keep running the ADSR sequence

for as long as the signal stays above

threshold, but are capable of retriggering

MODIFIER

during the ADSR sequence.

Sustain - Will stay at Sustain level for as long as

the signal stays above threshold.

Sust-Retrig - Will stay at Sustain level for as long as

the signal stays above threshold, but is

capable of retriggering during the

ADSR sequence.

Threshold

When the input level exceeds this level, the ADSR is

triggered.

LFO 1&2

The LFO’s can be used for various purposes, for example

you can connect a balance parameter and create an extra

panner or modulate a filter to create an auto-wah effect.

Both LFO1 & 2 have two outputs, which means that you

can use the same LFO with different phase for different

purposes.

Speed - The speed of the LFO also known as Rate.

Depth - The depth of the LFO also known as Width.

Tempo - Sets the LFO speeds relationship to the

tapped tempo (on the Tempo key). The

subdivisions available are: Ignored1/1, 1/2-

1/32, straight, dotted or triplets.(1/4 equals

BPM (beats per minute).

Curve - Select the curve that you would like on the

current LFO.Choose between: Square, Sine,

and Triangle.

Pulsewidth

Controls the division of the upper and lower parts of the

current curve, i.e. if Pulsewidth is set to 75%, the upper

half of the curve will be on for 75% of the time.

Square

Triangle

Sine
