Tc Electronic G-FORCE [35/63] The blocks

Algorithms

This chapter will go through all Edit parameters in

the eight blocks and the Input and Output sections.

Mute mode

The eight effect blocks all have a number of different

Mute modes. They are located as the last parameter in

the Edit list of each block.

The idea is that you can decide how every single block

should react when you push the current blocks bypass

key on the front panel. Here is the description of what

the five modes will do when bypassed:

Mix 0%: Will mute the output of effect, and take direct

signal level up to 100% dry = 0% effect.

FX Out: Will mute the output of the effect, and

preserve direct signal level, according to Mix.

Output : Will mute both the output of the effect and the

direct signal.

FX In : Will mute the input of the effect, and preserve

the direct signal level. This enables the block

to finish an effect tail after being bypassed,

e.g. using this mute mode on a delay will let

the delay tail ring out even after being

bypassed or at preset change between two

presets with the same settings (only the

Delay, Reverb and Pitch has this mute mode).

Input: Will mute both the input of the effect and the

direct signal. Same basic function as FX In,

only this mode will also mute the direct

signal. (only the Delay, Reverb and Pitch have

this mute mode).

Using the Input/Output mute modes will mean

that no signal passes through the current block

when bypassed.

THE BLOCKS

Gate

The basic idea about a Gate is that when the input

signal falls below a threshold set up by you, the Gate

turns down the signal by a certain number of dB’s, also

set by you.

Example:

You set the Threshold at -25dB and the Max.

damping at 30dB. When playing signal into the G-

Force, the Gate will not do anything, but when the input

signal is lower than -25dB (on the input meter) the

Gate will start damping to a maximum of 30dB (see the

Noise Gate meter). The speed of the damping is set by

the Release rate parameter (Rel.rate).

In the In-section of the G-Force, you find the Noise Gate.

The gain reduction of the Noise Gate is displayed by

the LEDs below the Billboard.

The Noise Gate (including the Level parameter) is not

bypassed by the overall Bypass key. This means that

the Noise Gate will still be active even if you bypass all

the effects of the G-Force.

NOISE GATE

Mode

Using the mode selector, you can choose between

Hard and Soft Gating. Hard damps almost

instantaneously when the Input falls below the

Threshold, while Soft damps gradually, meaning

damping very smooth and soft, without destroying your

sustain.

Threshold

When the input level falls below this Threshold, the

Noise Gate is activated.

Max. Damping

The maximum of dB’s that the Noise Gate can damp

(also called gain reduction), meaning if Max. Damping

is set to 0 dB, the Noise gate will not damp at all. The

damping/Gain reduction is displayed on the meters

below the Billboard.
