13
Start-up
Vacuuming dry material
Put a filter bag in the container before starting the cleaner.
The filter element will be wet after vacuuming wet material.
A damp filter element blocks quicker when vacuuming dry matter.
For this reason you should always use a dry filter element when vacuuming
dry material.
Do not vacuum aggressive solid matter.
Do not vacuum smoldering objects (hot ash,
embers etc.).
Do not vacuum combustible or explosive matter
(eg, magnesium, aluminium etc.).
Vacuuming liquids and mud
Always remove the filter bag before vacuuming liquids.
The use of special wet filter elements (order number 58 400 5) is
recommended.
The sensors will automatically shut down the vacuum when maximum
capacity is reached.
Do not vacuum combustible or explosive liquids
(eg, petrol, paint thinners etc.).
Do not vacuum aggressive liquids or solid matter
(acides, lyes, solvents etc.).
Compressed air
All cleaners have a compressed air aperture.
A suction hose can be fitted to this aperture.
The aperture has a cap which automatically
opens when the suction hose is fitted.
The cap closes when the hose is removed
and the cleaner switched off.
