![Kranzle Ventos 35 [35/40] Vento_35](/views2/1119857/page35/bg23.png)
35
Item Description Qty Order no.
1 Schale links 1 45 420 2
2 Schale rechts 1 45 420 3
3 Schlaufenteil 1 45 420 4
4 Gurtschlaufe 1 45 411 5
5 Deckel 1 1 45 420 5
6 Deckel 2 1 45 420 6
7 Kunststoffschraube 3,5 x 12 10 45 429 6
8 Schieber 1 45 420 7
9 Gleitstück 1 45 420 8
10 Kunststoffschraube 3,5 x 8 1 45 421 7
11 Druckfeder 1 45 420 9
12 Zylinderstift 3,0 x 21 1 45 421 0
13 Verlängerung 1 45 478 6
14 Düsenhalter 1 45 407 8
15 Kunststoffsenkschraube 5,0 x 22 2 45 421 1
16 Steckführung 1 45 423 1
17 Gummifeder 1 45 437 3
Handle compl. 45 477 9
consisting of items 1- 12
Suction handle compl. 45 477 8
consisting of items 1- 16
Spare parts list KRÄNZLE VENTOS 25 / 35
Suction handle
KRÄNZLE VENTOS 25 / 35
