Kranzle Ventos 35 [23/40] Vento_23
![Kranzle Ventos 35 [23/40] Vento_23](/views2/1119857/page23/bg17.png)
23
Item Description Qty Order no.
1 Saugschlauch DN 36 x 3,5 m 1 45 281 9
2 Sauggriff 1 45 477 8
3 Zubehörbox 1 45 473 1
4 Typenschild für Ventos 25 1 45 236 1
4.1 Typenschild für Ventos 35 1 45 236 2
6 Filtersack für Ventos 25 (5 Stück) 45 413 9
6.1 Filtersack für Ventos 35 (5 Stück) 45 414 0
12 Faltenfilter (2 Stück) 45 470 0
13 Schmutzeimer Ventos 25 kpl. mit Deckel 1 45 280 6
13.1 Schmutzeimer Ventos 35 kpl. mit Deckel 1 45 280 5
14 Netzanschlußkabel 1 45 235 7
16 Bodendüse mit 2 Einsätzen 1 58 402 1
17 Polsterdüse 1 58 400 9
18 Saugpinsel 1 58 400 8
19 Fugendüse 200 mm 1 58 400 7
20 Adapter Saugschlauch auf Zubehör 1 58 400 6
21 Verlängerung 50 cm 1 58 401 1
22 Handrohr gebogen mit Luftschieber 1 58 401 3
Spare parts list KRÄNZLE VENTOS 25 / 35
Complete cleaner
KRÄNZLE VENTOS 25 / 35
