31
Item Description Qty Order no.
1 Fahrwerk mit Dichtung 1 45 302 5
2 Lenkrolle D100 Tandem 2 45 208 3
3 Drehachse 2 45 307 3
5 Radkappe 2 45 200 8
7 Bremshebel 2 45 221 1
10 Scheibe 40 x 6 x 1,5 (Stahl) 2 45 216 7
11 Rad komplett 2 45 303 6
12 Dämmklotz 2 45 236 7
14 Blasluftklappe 1 45 200 4
15 Abluftboden 1 45 200 3
17 Winkelhutze 1 45 307 1
21 Behältermodul 1 45 307 4
22 Türe Staufach 1 45 307 5
23 Riegel für Türe 1 45 206 8
31 Behälteroberteil 1 45 303 8
32 Lagerschalensatz 1 45 303 4
38 Ansaugrohr mit Dichtring 1 45 307 2
40 Kabelhalter mit Schraube und Mutter 1 45 303 5
41 Steckhalter 1 45 225 7
42 Vierkantmutter M 6 2 45 245 3
43 Schraube M 6 x 25 DIN 7985 2 45 217 0
Spare parts list KRÄNZLE VENTOS 35
Chassis
KRÄNZLE VENTOS 35
