Kranzle Ventos 35 [39/40] Vento_39
![Kranzle Ventos 35 [39/40] Vento_39](/views2/1119857/page39/bg27.png)
39
I. Kränzle GmbH
Elpke 97 . 33605 Bielefeld
Hochdruckreiniger
High-pressure-cleaners
Nettoyeurs À Haute Pression
Herewith we declare
that
comply with the following
provisions applying to it
Applied
harmonized standards
in particular
EC declaration of conformity
Bielefeld, den 23.11.04
(Managing Director)
Kränzle Ventos 25
Kränzle Ventos 35
Maschinenrichtlinie 89/392/EWG
Niederspannungsrichtlinie 73/23 EWG
EMV-Richtlinie 89/336 EWG
Lärmrichtlinie 2000/14/EG
EN 60 335-2-79:2004
EN 55 014-1 / A2:2002
EN 55 014-2 / A1:2001
EN 61 000-3-2 / A14:2000
EN 61 000-3-3 / A1:2001
