Item Description Qty Order no.
1 Haube mit Pos. 3 1 45 305 3
3 Klammern 1 45 305 4
5 Verschlußklammer 2 45 220 9
6 Griff 1 45 300 5
12 Drehknopf Saugleistung 1 45 305 5
13 Blende 1 45 300 8
16 Schalter EIN / AUS 1 45 305 6
18 Steuerplatine 1 45 305 7
20 Griff Abreinigung 1 45 301 2
22 Abreinigungsgabel 1 45 305 8
23 Lagerbolzensatz 1 45 301 8
26 Filtergehäuse 1 45 305 9
28 Dichtungssatz Haube 1 45 306 0
30 Wasserkontakt (2x) 1 45 306 1
31 Filterkasette 2 45 202 0
32 Litzensatz 1 45 306 2
34 Filter element main filter (2 pcs.) 45 470 0
Spare parts list KRÄNZLE VENTOS 25 / 35
