bizhub PRESS 2250P 1-5
1.2 Conventions used in this manual
1
d Reference
This symbol indicates a reference.
View the reference as required.
Key symbols
[ ]
Key names on the touch panel or computer screen, or a name of user's guide are indicated by these brackets.
Bold text
Key names on the control panel, part names, product names and option names are indicated in bold text.
1.2.2 Paper indications
Paper size
The following explains the indication for paper described in this manual.
When indicating the paper size, the Y side represents the width and the
X side the height.
Paper indication
w indicates the paper size with the height (X) being longer than the
width (Y).
v indicates the paper size with the height (X) being shorter than the
width (Y).
