![Konica Minolta bizhub PRESS 2250P [255/315] Using pagescope web connection](/views2/1121983/page255/bgff.png)
bizhub PRESS 2250P 16-2
16.1 Using PageScope Web Connection
16
16 PageScope Web Connection
16.1 Using PageScope Web Connection
PageScope Web Connection is a device control utility. Using a Web browser on a computer connected to
the network, you can change machine settings and check the status of the machine.
This function is unavailable while the Enhanced Security mode is activated.
This function is unavailable with the PSWC setting set to [Disable]. For details, see [06 Administrator Setting]
- [04 Network Setting] - [02 Controller NIC Set. (Body 1)] - [03 HTTP Server Setting].
16.1.1 Operating environment
To fully access all the features of PageScope Web Connection, the operating computer should meet the fol-
lowing requirements.
You can choose Flash or HTML to view the PageScope Web Connection. To view the Flash page, Adobe
Flash Player Ver. 7.0 or higher needs to be installed on the computer.
16.1.2 Accessing PageScope Web Connection
0 Start the Web browser to access PageScope Web Connection.
0 If User Authentication is enabled, enter the user name and password. For details, refer to page 16-10.
0 For details on specifying the IP address for the machine, refer to [User's Guide - Main Body].
0 PageScope Web Connection has two view modes: Flash and HTML. For details, refer to page 16-9.
1 Start the Web browser.
2 Enter the IP address of the machine in the URL field, and then press [Enter].
http://<IP address of the machine>/
Example : When the IP address of this machine is 192.168.1.20 :
- http://192.168.1.20/
When IPv6 is set to [ON] while a browser other than Internet Explorer 6 is used:
- Enter the IPv6 address enclosed in brackets [ ] to access PageScope Web Connection.
- http://<IP address of the machine>/
Example : When the IPv6 address of this machine is fe80::220:6bff:fe10:2f16:
- http://[fe80::220:6bff:fe10:2f16]/
- If IPv6 is set to [ON], add "fe 220::6:10bff:fe:2:6f IPv:1_MFP" to the hosts file in advance, and specify
the address with the domain name.
Operating System Web Browser
Windows XP, Server 2003, Vista, Server
2008, Server 2008R2, Windows 7, 8,
Server 2012, Windows 8.1, Server 2012
R2
Microsoft Internet Explorer 8 or higher (recommended) (Ja-
vaScript and Cookie enabled)
Mozilla Firefox 7.0 or higher (recommended) (JavaScript and
Cookie enabled)
Macintosh OS X Mozilla Firefox 7.0 or higher (recommended) (JavaScript and
Cookie enabled)
Linux Mozilla Firefox 7.0 or higher (recommended) (JavaScript and
Cookie enabled)
Operating System Screen Reader
Windows XP, Server 2003, Vista, Server
2008, Windows 7, 8, Server 2012, Win-
dows 8.1, Server 2012 R2
JAWS for Windows Version 4.5 or higher
