bizhub PRESS 2250P 5-30

5.3 Windows XP/Server 2003

5.3.3 For network connection (IPP/IPPS)

To use IPP printing, specify the port while installing the printer driver.

Settings of this machine

To use IPP printing, you must configure the network settings for the machine in advance.

d Reference

For details on the network settings for this machine, refer to [User's Guide - Main Body].

Before you can use IPPS printing, you must register a certificate with this machine. You can use the self-

signed certificate that is preinstalled in this machine. For details, refer to [User's Guide - Main Body].

Installing the printer driver using the Add Printer Wizard

0 Installing the driver to Windows XP/Server 2003-based computers requires the administrator authority.

1 Insert the Driver CD-ROM into the CD-ROM drive.

2 Click [Start], and then select [Printers and Faxes].

% If [Printers and Faxes]is not displayed in the [Start] menu, open [Control Panel] from the [Start] menu,

click [Printers and Other Hardware], then click [Printers and Faxes].

3 In Windows XP, select [Add a printer] from the [Printer Tasks] menu.

In Windows Server 2003, double-click [Add Printer].

4 Click [Next >].

5 In the [Local or Network Printer] page, select [A network printer, or a printer attached to another com-

puter], and then click [Next >].

6 In the [Specify a Printer] page, select [Connect to a printer on the Internet or on a home or office net-

work:].

7 In the [URL:] field, enter the URL for the machine in the following format, and then click [Next >].

% http://<IP address for the machine>/ipp

Example: When the IP address for the machine is 192.168.1.20, http://192.168.1.20/ipp

% When specifying to use IPPS printing, enter "https://<IP address for the machine>/ipp".

% If a confirmation dialog box appears after clicking [Next >], click [OK].

8 Click [Have Disk...].

9 Click [Browse...].

10 Select a desired printer driver folder in the CD-ROM, and then click [Open].

% Select a folder according to the printer driver, operating system, and language to be used. Available

printer drivers: PCL driver, PS Plug-in driver, PPD driver

11 Click [OK].

The [Printers] list appears.

12 Click [OK].

13 Follow the instructions on the pages that follow.

14 Click [Finish].

Items to be configured Description

IP Address In [TCP/IP Settings] of this machine, specify the IP address.

IPP Setting In [HTTP Server Setting] for the machine, enable IPP printing.
