Konica Minolta bizhub PRESS 2250P [16/315] Control panel layout

bizhub PRESS 2250P 2-4

2.1 What is the image controller?

2.1.3 Control Panel Layout

No. Name Description

1 Keypad Enters numeric values.

2 Power LED Lights up in red when the main power switch is

turned on, then turns green when the sub power

switch is turned on.

3 Data LED Flashes while the machine is receiving print data.

4 Stop Suspends the current output job or stops the machine

operation.

5 Start Activates various machine operations.

6 Start LED Lights up in blue when the machine is ready to oper-

ate.

It turns orange when any operation cannot be started.

7 C (Clear) Allows change in entered numeric value.

8 Access Sets the machine to allow the operation only when the

next user is authenticated, if user authentication or

account track function is activated and an authenti-

cated user has used the machine.

9 Mode Check Used to the Mode Check Screen to check the current

print job settings.

10 Utility/Counter Displays the Utility Menu Screen and various coun-

ters.

11 Accessibility Adjusts the response time in touch panel and control

panel key operation.
