bizhub PRESS 2250P 13-12
13.4 Parameter details
13
Reference
- The [Perfect Binder] function is available only when an optional [Perfect Binder] is installed.
Perfect Binding Mode
Perfect Binding mode has the following 4 types:
[Perfect Binding
Settings]
[Off], [Cover Blank]
[Cover Print 1in1]
[Cover Print 2in1]
[Cover Print 3in1]
Set this when using a perfect binder function.
For detail, refer to page 13-12.
[Perfect Binding
Cover Tray]
Off, Tray 1-11
PI Tray 1-2
PI-PFU Tray 1-3
PB Cover Tray
You can set a cover tray for a perfect binder.
[Perfect Binding
Cover Duplex]
Off, On Set this when setting a duplex cover for a perfect bind-
er.
[Perfect Binding
Cover Trim]
Off, On Set this when trimming a cover for a perfect binder.
Function Name Option Description
Cover Blank
Cover Print 2in1 Cover Print 3in1
Cover Print 1in1
Function Name Description
[Cover Blank] Cover wraps the body of document without being printed.
[Cover Print 1in1] This is used when arrangements are made in advance for the originals the front
cover, the back cover and the spine of which have been cut and pasted to the
same size as the paper used as the front cover.
[Cover Print 2in1] For the front cover, the first page and the last page (n page) of the originals are
made as 2in1, and the second page up to the last page but one (n - 1 page) are
printed as the body of documents with no printing made on the spine for perfect
binding.
[Cover Print 3in1] After cutting and pasting automatically the first page of the original on the front
cover, the last page but one (n - 1 page) on the back cover, and the last page
(n page) on 3in1 as the spine, the front cover is printed.
And the second page up to the last page but two (n - 2 page) are printed as the
body of documents.
Содержание
- Before installing the printer driver 3
- Contents 3
- Installing the windows printer driver 3
- Introduction 3
- Manual installation using the add printer wizard 3
- Overview 3
- Basic printing methods and printer functions 4
- Installation on macintosh computers 4
- Installation when using netware 4
- Print functions of pcl driver for windows 4
- Uninstalling the printer driver 4
- Print functions of ppd driver for mac os x 5
- Print functions of ppd driver for windows 5
- Print functions of ps plug in driver 5
- Function details 6
- Pagescope web connection 6
- Settings on the control panel 6
- Appendix 7
- Product specification report 7
- Troubleshooting 7
- Utility tool 7
- Composition of user s guide 9
- Introduction 9
- User s guide 9
- Welcome 9
- Conventions used in this manual 11
- Procedural instruction 11
- Safety information 11
- Symbols used in this manual 11
- The operation procedures are described using instruction 11
- Key symbols 12
- Paper indication 12
- Paper indications 12
- Paper size 12
- Reference 12
- Overview 14
- Role of the image controller 14
- What is the image controller 14
- Bizhub press 2250p 2 3 15
- Print data sent from an application is received by the printer driver 15
- Print flows 15
- The data is sent to the image controller via the usb interface for usb connection or via ethernet tcp ip etc for network connection then the data is passed from the image controller to the machine the image controller rasterizes images expands output target characters and images to bitmap data this data is print ed from the machine 15
- The following outlines the flow of operations for using this printing system as a printer 15
- What is the image controller 15
- Control panel layout 16
- Caution 17
- Notice 17
- Reference 17
- Macintosh 18
- Operating environment 18
- Supported computers and oss 18
- Windows 18
- Connection diagram 19
- Ethernet 19
- Interfaces used for connection 19
- Usb interface 19
- For local connection 20
- For network connection 20
- Setup procedure 20
- Before installing the printer driver 22
- Introduction 22
- Printer drivers compatible with respective operating systems 22
- Connection methods selectable in each operating system 25
- Windows 8 server 2012 windows 8 server 2012 r2 25
- Reference 26
- Windows vista server 2008 server 2008 r2 7 26
- Reference 27
- Windows xp server 2003 27
- Mac os x 10 10 10 10 10 28
- Netware 28
- Reference 28
- About installer 30
- Installing the windows printer driver 30
- Operating environment of the installer 30
- Easy installation procedure using the installer 32
- Raw port number ipp setting for this machine 32
- Settings of this machine 32
- Tcp ip settings for this machine 32
- Installing the printer driver pcl driver 33
- Installing theprinter driver ps plug in driver 36
- For network connection lpr port 9100 smb 40
- Installing the printer driver by searching for the printer using the add printer wizard 40
- Manual installation using the add printer wizard 40
- Settings of this machine 40
- Windows 8 server 2012 windows 8 server 2012 r2 40
- Installing the printer driver by creating a printer port 42
- For network connection ipp ipps 44
- Installing the printer driver using the add printer wizard 44
- Settings of this machine 44
- For network connection web service print 46
- Making the printer driver known from the network window 46
- Settings of this machine 46
- For local connection 47
- Making the installed printer driver known to the computer 47
- Updating the driver after connecting this machine 47
- For network connection lpr port 9100 smb 49
- Installing the printer driver by searching for the printer using the add printer wizard 49
- Settings of this machine 49
- Windows vista server 2008 server 2008 r2 7 49
- Installing the printer driver by creating a printer port 52
- For network connection ipp ipps 54
- Installing the printer driver using the add printer wizard 54
- Settings of this machine 54
- For network connection web service print 56
- Making the printer driver known from the network window 56
- Settings of this machine 56
- Installing the printer driver by specifying the ip address using the add printer wizard 57
- For local connection 60
- Installing the printer driver when connecting the machine 60
- Making the installed printer driver known to the computer 60
- Notice 60
- Updating the driver after connecting this machine 61
- For network connection lpr port 9100 62
- Installing the printer driver using the add printer wizard 62
- Settings of this machine 62
- Windows xp server 2003 62
- For network connection smb 65
- Installing the printer driver by specifying the printer using the add printer wizard 65
- Settings of this machine 65
- For network connection ipp ipps 68
- Installing the printer driver using the add printer wizard 68
- Settings of this machine 68
- For local connection 69
- Notice 69
- Installation on macintosh computers 71
- Installing the ps plug in driver 71
- Printer driver for mac os 71
- Installing the ps ppd driver 72
- Adding a printer 73
- Configuring the bonjour settings 73
- Selecting and connecting a printer 73
- Configuring appletalk setting for the computer 74
- Configuring the appletalk settings 74
- Adding a printer 75
- Configuring tcp ip setting for the computer 76
- Configuring the lpr settings 76
- Adding a printer 77
- Configuring the ipp settings 78
- Adding a printer 79
- Configuring tcp ip setting for the computer 79
- Configuring the windows client 82
- Installation when using netware 82
- Netware 82
- Network settings 82
- Uninstalling by the installer pcl driver 84
- Uninstalling the printer driver 84
- Windows 84
- Uninstalling by the uninstallation program pcl driver 85
- Uninstalling by manual operation ps plug in driver ppd driver pcl driver 86
- Windows xp server 2003 vista server 2008 server 2008 r2 7 86
- Windows 8 server 2012 windows 8 server 2012 r2 87
- Mac os 10 10 10 88
- Macintosh 88
- Uninstalling by manual operation ps plug in driver 88
- Mac os 10 10 89
- Mac os 10 10 90
- Mac os 10 10 10 90
- Uninstalling by manual operation ps ppd driver 90
- Basic printing method windows 93
- Basic printing methods and printer functions 93
- Print operations 93
- Basic printing method mac os x 94
- Print options 94
- Setting items 94
- Portrait landscape 95
- Printer functions 95
- Setting paper 95
- Setting the paper size for the output paper 95
- Setting the paper type 95
- Setting the print orientation 95
- Document 96
- Enlargement 96
- Enlarging reducing an original by specifying a value 96
- Reduction 96
- Setting paper color 96
- Setting the pre punched paper 96
- Setting a paper source unit 97
- Setting a paper tray 97
- Setting a paper output unit 98
- Setting an output tray 98
- To set the stacker 99
- Printing a number of sets of an original 100
- Printing an original by set sort 100
- Printing an original in a collating order 100
- Setting a number of copies 100
- Offsetting outputted copies by each unit offset 101
- 14 15 16 102
- Printing more than one page 102
- Printing more than one page in a sheet of paper combination layout 102
- Setting a 2 sided printing 102
- Printing 2 pages in a double sized sheet of paper combination 103
- Printing a booklet for folding into two booklet 103
- Printing in chapters chapter 103
- Outputting pages with their faces up face up 104
- Setting a back cover 105
- Setting a front cover 105
- Setting a front cover back cover interleaf and cover 105
- Inserting a tab 106
- Setting a cover 106
- Abcdef 107
- Setting a punch kit 107
- Setting finishing 107
- Setting hole punching 107
- Setting stapling 107
- Ab abc abc abc abc abc abc 108
- Abc abc 108
- Abc abc abc 108
- Adjusting a print position binding margin 108
- Adjusting a print position image shift 108
- Setting binding and folding 108
- Back cover inside 109
- Body of documents 109
- Documents to the spine 109
- Front cover inside 109
- Pasting of the body of 109
- Spine front cover outside back cover outside 109
- To set perfect binding 109
- Creating a transparent pattern overlay 110
- Printing a page number 110
- Printing an original with numbering 110
- Printing date time 110
- Setting transparent 110
- Printing a line smoothly 111
- Setting a resolution at printing 111
- Setting an image 111
- Smoothing 111
- Saving and printing a job save print save 112
- Saving and reprinting a job 112
- Setting a password for a print job secure print 112
- Default settings of the printer driver 114
- Displaying the properties window 114
- Print functions of pcl driver for windows 114
- Configure tab 115
- Settings tab 116
- About tabs provided by os 117
- Reference 117
- Registering the default settings 118
- Common setting 119
- My tab 121
- Parameter details 121
- Edit my tab 122
- Basic tab 123
- Mm 324 mm 125
- Layout tab 126
- Combination detail 128
- Binding margin settings 129
- Image shift settings 130
- Finish tab 131
- Perfect binding settings 133
- Perfect binding mode 134
- Cover mode tab 135
- Per pages setting edit list 136
- Tab paper settings 137
- Stamp composition tab 138
- Edit watermark 139
- Editing overlay 140
- Editing date time page number 141
- Editing distribution number 141
- Quality tab 142
- Font settings 143
- Quality adjustment 143
- Other tab 144
- Default settings of the printer driver 146
- Displaying the configure screen 146
- For windows 146
- Print functions of ps plug in driver 146
- For mac os x 147
- Common setting 148
- General tab 149
- Parameter details 149
- Mm 324 mm 150
- Layout tab 151
- Finishing tab 153
- Output tab 155
- 1 2 1 2 2 1 2 1 156
- 4 3 4 2 4 3 4 2 4 3 4 156
- 4 4 3 43 4 3 4 3 4 3 2 3 156
- Bizhub press 2250p 11 12 156
- Example of offset 156
- Offset out put copies 1 3 3 156
- Offset out put copies 2 1 2 156
- Offset out put sheets 2 156
- Output cop ies set unit 1 1 3 156
- Output cop ies set unit 2 4 4 156
- Parameter details 156
- Sort group sort sort group 156
- Sort group sort sort sort 156
- Values are unacceptable 156
- Paper tab 157
- Tray settings 157
- Paper name 158
- Paper size 158
- Cover tab 159
- Perfect binding mode 160
- Page settings tab 161
- Tabs tab 162
- Space above 163
- Space below 163
- Tab height 163
- Tab settings tab 163
- 0 imaging tab 165
- 1 forms tab 167
- 2 image position tab 168
- 3 stamp tab 169
- 4 workflow tab 170
- Notice 171
- 5 authent tab 172
- 6 configure tab 174
- Device options tab 174
- Reference 174
- Driver options tab 175
- Snmp settings tab 175
- 7 version tab 176
- 8 advanced tab 177
- Default settings of the printer driver 179
- Displaying the properties window 179
- Print functions of ppd driver for windows 179
- About tabs provided by os 180
- Device settings tab 180
- Registering the default settings 181
- Common setting 182
- Layout tab 183
- Parameter details 183
- Paper quality tab 184
- Advanced options window 185
- Perfect binding mode 189
- Reference 189
- Default settings of the printer driver 191
- Option settings 191
- Print functions of ppd driver for mac os x 191
- Reference 192
- Registering the default settings 192
- Common setting 193
- Adding the custom size 194
- Page attributes 195
- Parameter details 195
- Copies pages 196
- Finishing 197
- Reference 198
- Image layout 199
- Perfect binding mode 201
- Secure print 202
- Creating a user box secure folder 204
- Function details 204
- Secure print 204
- Pcl driver 208
- Printer driver settings pcl driver ps plug in driver ppd driver mac os x 208
- Ps plug in driver 209
- Calling a job from the control panel 210
- Ppd driver mac os x 210
- Print from the secure folder 210
- Delete a user box in a secure folder 213
- Creating a personal folder 215
- Save in user box 215
- Creating a user box 216
- Pcl driver 218
- Printer driver settings pcl driver ps plug in driver ppd driver mac os x 218
- Ppd driver mac os x 219
- Ps plug in driver 219
- Calling a job 220
- Print from recall tab 220
- Deleting a personal folder 223
- Deleting a user box in a personal folder 224
- Deleting a user box in a public folder 226
- Pcl driver 228
- Printer driver settings pcl driver ps plug in driver ppd driver mac os x 228
- Proof print wait mode hold print 228
- Ps plug in driver 229
- Ppd driver mac os x 230
- Ppd driver windows 230
- Calling a job 231
- Calling a job sent by proof print proof and print 1st sheet wait mode 231
- Print from recall tab 231
- Calling a job sent by hold print 232
- Select a job from the job list tab 232
- Printing a document on the machine for which user authentica tion is specified 233
- Printing a document on the machine for which user authentication is specified 233
- Setting a user authentication pcl driver 233
- Setting a user authentication ps plug in driver 234
- Printing a document on the machine for which account track function is enabled 235
- Setting an account track pcl driver 235
- Setting an account track ps plug in driver 236
- Controller machine setting 238
- Displaying the controller screen 238
- Settings on the control panel 238
- Controller machine setting menu screen 239
- Reference 240
- Report type 240
- Direct print setting 241
- Direct print setting basic settings 241
- Direct print setting pcl setting 243
- Direct print setting ps setting 244
- Direct print setting tiff setting 244
- Notice 245
- Select printer setting 245
- Spool print jobs in hdd before rip 245
- I f timeout sec 246
- Plug in form password 246
- Administrator settings 247
- Basic operations of user settings 248
- Displaying the utility menu screen 248
- Function setting 249
- Basic operations in administrator settings 250
- Displaying the administrator settings screen 250
- Administrator setting screen 251
- Reference 251
- Controller nic setting menu 252
- Displaying the controller nic setting screen 252
- Reference 253
- Accessing pagescope web connection 255
- Operating environment 255
- Pagescope web connection 255
- Using pagescope web connection 255
- For internet explorer 257
- For mozilla firefox 257
- Online help function 257
- Web browser cache 257
- Login and logout 258
- Login and logout flows 258
- When user authentication or account track is not enabled 258
- When user authentication or account track is enabled 259
- Logout 261
- Logging in as a public user 262
- Login options 262
- Logging in as a registered user 263
- Logging in to the administrator mode 264
- 6 7 4 5 265
- Structure of pages 265
- Information 267
- Overview of the user mode 267
- Direct print 269
- Administrator mode overview 270
- Maintenance 270
- Security 271
- Printer setting 272
- Network 273
- Font management utility 275
- Reference 275
- Utility tool 275
- Cannot print 277
- Troubleshooting 277
- Cannot configure the settings cannot print according to the set tings 279
- Cannot configure the settings cannot print according to the settings 279
- The printer driver settings have no effect 279
- Others 280
- Product specification report 282
- Product specifications 282
- Configuration page print 286
- Printing reports 286
- Pcl demo page print 294
- Ps demo page print 295
- Pcl font list 296
- Ps font list 299
- Appendix 304
- Configuring the ppd driver for linux 304
- Ppd driver for linux 304
- Ppd driver for linux and applications 304
- Ppd driver types 304
- Registering the ppd driver for linux 304
- Registering the ppd driver for openoffice 304
- How to print 305
- Ppd driver for applications 305
- Printing with openoffice 305
- Glossary 306
- Index by item 311
- Numerics 311
- Index by button 313
Похожие устройства
- Opel INSIGNIA MY 12.5 (2012) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 1050 Инструкция по эксплуатации
- Opel ZAFIRA MY 9.0 (2009) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 1050e Инструкция по эксплуатации
- Opel ZAFIRA MY 9.5 (2009) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 1050eP Инструкция по эксплуатации
- Opel ZAFIRA MY 10.0 (2010) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 1050P Инструкция по эксплуатации
- Opel ZAFIRA MY 11.0 (2011) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 1051 Инструкция по эксплуатации
- Opel ZAFIRA MY 11.5 (2011) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 1200 Инструкция по эксплуатации
- Opel ZAFIRA MY 12.0 (2012) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 1200P Инструкция по эксплуатации
- Opel MERIVA MY 10.5 (2010) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 1600P Инструкция по эксплуатации
- Opel MERIVA MY 11.0 (2011) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 2000P Инструкция по эксплуатации
- Opel MERIVA MY 12.0 (2012) Инструкция по эксплуатации
- Konica Minolta bizhub PRO 2500P Инструкция по эксплуатации
