bizhub PRESS 2250P 2-5
2.1 What is the image controller?
2
7 CAUTION
Do not press hard or pointed objects against the touch panel on the control panel.
- Otherwise, the glass may be scratched or break and you may be injured. Use fingers to operate the
touch panel.
7 CAUTION
Stop the operation immediately when the Service Call Screen is displayed and printing cannot be continued
any more.
- Otherwise, an unexpected trouble may be caused. Write down the report code as stated on the 2nd
line of the message, turn off the sub power switch and main power switch in this order, then discon-
nect from the power socket. Contact your service representative and inform them of the report code.
NOTICE
The main power switch should normally be kept turned on. Be sure not to turn off/on the main power switch
in usual operation.
Be sure not to turn off the main power switch before turning off the sub power switch.
Be sure not to turn off the main power switch while the following messages are displayed after turning off
the sub power switch.
[Cooling in progress / After cooling, power off automatically]
[Power off in progress / Please do not turn the main power off]
Turning off the main power switch with these messages displayed may cause machine trouble such as toner
fixation.
d Reference
For details on turning off the power supply, refer to [User's Guide - Main Body].
12 Help Displays the Help Screen that provides information on
how to operate the screen currently displayed on the
touch panel.
Also provides information on various supplies and
disposals when pressed with the Machine Screen dis-
played.
13 Brightness adjustment dial Turned to adjust the brightness of the touch panel.
14 Power Save Enables temporary use of the machine when the
Power Save LED is lit. Also, activates power-saving
mode when pressed while the machine is inactive.
15 Power Save LED Lights when any power-saving mode is activated, or
machine power is off due to the weekly timer function.
16 Touch panel Displays various screens to allow the function setting.
