Konica Minolta bizhub PRESS 2250P [167/315] 1 forms tab

bizhub PRESS 2250P 11-23

11.3 Parameter details

11.3.11 [Forms] tab

The form image file can be superimposed.

Select [Workflow] tab - [Output Method] - [Form] to save a form file. For details, refer to page 11-26.

Function Name Option Description

[Acquire Form

Data]

- Communicate with the machine to acquire the form in-

formation saved in the image controller.

When appears at the right of [Acquire Form Data], it

means that the form information has been acquired.

[Form] [Off], [Registered form

name.]

Set the form function.

[Forms Print

Mode]

[Repeated], [Once] Select [Repeated] to overlay all form pages repeatedly

in order from the first page on a printing document.

Select [Once] to overlay all forms pages only once in or-

der from the first page on a printing document.

[Per Page Set-

tings]

[Form], [Page Number] You can set an overlay on a page basis.

However, the maximum number will be different de-

pending on the selected form and page.

[Prepend] [Off], [Registered form

name.]

Set the selected form before the current job.

[Append] [Off], [Registered form

name.]

Set the selected form after the current job.

[Copy to Clip-

board]

- Click to copy the preview page to the clipboard.

You can check a layout by pasting the image from the

clipboard onto a printing document.

[Clear Form] - Click to clear the selected form from the image control-

ler. You need to input a password to clear the form.

The password is set in the machine. For details, refer to

page 15-10.
