Konica Minolta bizhub PRESS 2250P [79/315] Configuring tcp ip setting for the computer

bizhub PRESS 2250P 6-10

6.1 Printer Driver for Mac OS

Configuring TCP/IP Setting for the computer

Configure the TCP/IP settings for the Macintosh computer connected to the printer.

1 In the [Apple Menu], select [System Preferences...].

2 Click the [Network] icon.

3 The Ethernet setting window appears.

% For OS X 10.5/10.6/10.7/10.8, select [Ethernet], and then click [Advanced...].

% For OS X 10.4, select [Built-in Ethernet], and then click [Configure...].

4 Click the [TCP/IP] tab.

5 Configure the settings including the IP address and subnet mask according to the settings of the net-

work to which the Macintosh computer is connected.

6 Click the close button at the top left corner of the window.

% When the [This service has unsaved changes] message appears, click [Apply].

Adding a printer

1 In the [Apple Menu], select [System Preferences...].

2 Click the [Print & Fax] icon.

3 Click [+] on the [Print & Fax] window.

[Printer Browser] appears.

4 Click [IP] or [IP Printer].

5 In [Protocol:], select [Internet Printing Protocol - IPP].

6 In [Address:], enter the IP address for this machine. In [Queue:], enter "ipp".

The printer driver corresponding to this machine being identified with its IP address is automatically se-

lected.

% After the printer driver is selected, go to Step 8.

% If an incorrect printer driver is selected, go to Step 7.

7 Select the desired printer driver manually.

% When OS X 10.6 /10.7/10.8 is used, select [Select Printer Software...] from [Print Using:], and then

select the printer driver of the desired model name from the list that is displayed in another window.

% When OS X 10.5 is used, select the [Select a driver to use...] from the [Print Using:], and then select

the printer driver of the desired model name from the list.
