bizhub PRESS 2250P 5-15

5.2 Windows Vista/Server 2008/Server 2008 R2/7

7 Specify the IP address and port.

% To use the LPR/Port 9100 protocol, select [TCP/IP Device], and then enter the IP address.

% To use the SMB connection, enter [\\NetBIOS name\print service name] in the "Port Name" box.

% Enter the same NetBIOS name and print service name specified in [SMB Setting] - [Print Setting].

8 Click [Next].

% If [Additional Port Information Required] or [More Port Information Required] dialog box appears, go

to Step 10.

% If the [Install the printer driver] dialog box appears, go to Step 13.

9 Select [Custom], and then click [Settings...].

10 Change the settings according to the port, and then click [OK].

% For LPR connection, select [LPR], and then enter "Print" in the [Queue Name:] box.

% You must discriminate between upper and lower case letters when entering it.

% For Port 9100, select [Raw], and then enter a RAW port number (initial setting: [9100]) in the [Port

Number:] box.

% If both LPR and Port 9100 are enabled on this machine, the printer driver is connected to this ma-

chine using LPR.

11 Click [Next].

The [Install the printer driver] page appears.

12 Click [Have Disk...].

13 Click [Browse...].

14 Select a desired printer driver folder in the CD-ROM, and then click [Open].

% Select a folder according to the printer driver, operating system, and language to be used. Available

printer drivers:

PS Plug-in driver, PPD driver, PCL driver

15 Click [OK].
