bizhub PRESS 2250P 5-26

5.3 Windows XP/Server 2003

10 Select [Custom], and then click [Settings:].

11 Change the settings according to the port, and then click [OK].

% For LPR connection, select [LPR], and then enter "Print" in the [Queue Name:] box.

% You must discriminate between upper and lower case letters when entering it.

% For Port 9100, select [Raw], and then enter a RAW port number (initial setting: [9100]) in the [Port

Number:] box.

12 Click [Next >].

13 Click [Finish].

14 Click [Have Disk...].

15 Click [Browse...].

16 Select a desired printer driver folder in the CD-ROM, and then click [Open].

% Select a folder according to the printer driver, operating system, and language to be used. Available

printer drivers: PCL driver, PS Plug-in driver, PPD driver

17 Click [OK].

The [Printers] list appears.

18 Click [Next >].

19 Follow the instructions on the pages that follow.

% To use a network connection, perform a test print after the network settings have been configured.

20 Click [Finish].

% If the "Windows logo testing" or [Digital Signature] window appears, click [Continue Anyway] or

[Yes].

21 After finishing the installation, make sure that the icon for the installed printer is displayed in the [Printers

and Faxes] window.

22 Remove the CD-ROM from the CD-ROM drive.

This completes the printer driver installation.
